About This Item
General Info
- Ergonomic, compact and minimalist design
- Easy loading and auto-cutter with partial or total cut
- Near paper end sensor adjustable from 15 mm to 20 mm
- Retractable service keyboard with 28 capacity buttons and backlight display
- Auto-calibration system minimizes manual interventions
- Automatic recovery and restart after a power failure
*Based on 2019 data and internal testing
![Connections](/wps/wcm/connect/marketing/d8f9b90e-1f04-4a3d-8c18-9e68253a9ead/usb-plug-red.png?MOD=AJPERES&CACHEID=ROOTWORKSPACE.Z18_KA0A1A02NGL3D0AVS7NACQ0000-d8f9b90e-1f04-4a3d-8c18-9e68253a9ead-no-3t0S)
CONNECTIONS
USB, micro USB, serial, ethernet and optional WiFi provide multiple options for connecting POS systems
![VERSATILE](/wps/wcm/connect/marketing/944808e3-7b26-48f0-a097-b4cd9c9fdc9a/vga-cable-red.png?MOD=AJPERES&CACHEID=ROOTWORKSPACE.Z18_KA0A1A02NGL3D0AVS7NACQ0000-944808e3-7b26-48f0-a097-b4cd9c9fdc9a-no-5s-N)
VERSATILE
Available with 58 and 80mm print head, print barcodes, QR codes and graphics on non-fiscal documents
![Flexibility](/wps/wcm/connect/marketing/a1de5d9e-f036-40f6-a289-1d8a323faa99/directions-red.png?MOD=AJPERES&CACHEID=ROOTWORKSPACE.Z18_KA0A1A02NGL3D0AVS7NACQ0000-a1de5d9e-f036-40f6-a289-1d8a323faa99-nmZYNVc)
FLEXIBILITY
Four ports for keyboards and displays: Two RS232-1 USB ports, one microUSB and one ethernet
![Drivers](/wps/wcm/connect/marketing/569805ff-f567-4776-a20f-c0adf38ea8da/disk-drive-red.png?MOD=AJPERES&CACHEID=ROOTWORKSPACE.Z18_KA0A1A02NGL3D0AVS7NACQ0000-569805ff-f567-4776-a20f-c0adf38ea8da-no-3wD3)
DRIVERS
Provided for the latest operating systems and peripherals
Specifications
Key Technical specifications :
- Print Speed 200 mm/s
- Thermal print head from 58 e 80 mm
- Print density 576 dots/line
- Paper roll diameter 80mm and using an optional redactor 58/60 mm
- Paper Width: 80mm
- Partial and complete paper cut
- Cutter Life: 2,0 mln. of cut
- Print Head Life: 100Km
- Number of characters per line: 41 (font standard)
- Number of transmissions of payments: 3000
- Permanent Detailed Memory (DGFE) dimension: 8GB (replaceable) up to 256 GB
- Paper end sensor
- Near paper end sensor(adjustable from 15mmto20mm)
- Always on (automatic recovery and restart after a power failure)
- Paper feed button
- Error reset button
- Optional deferred printing
- Header Logo for fiscal and non-fiscal printing programmable (optional printing from driver on nonfiscal document)
- Cash drawer port RJ11 with drawer status open/close sensor
- Cutter with auto-cutter with partial or total cut (controlled by driver)
- Buzzer
- Barcode printing (EAN13, EAN8, CODE39, EAN128, QRCODE)
- Graphical printing on nonfiscal documents
- Fiscal documents (invoices, credit notes, 12 VAR rates 6 of which for exemptions)
- Led printer status (on, error, no paper)
- 7 header lines programmable
- External power supply (24V 3A)
- Pull-out Service keyboard with 28 capacity buttons and a 2x16 back light display
